Three Axle Flatbed Semi-Trailer
1.A three axle flatbed semi-trailer has three axles, which can more effectively distribute the weight of goods, making each axle bear relatively less pressure, thereby improving the overall load-bearing capacity. Usually, its load-bearing capacity can reach several tens of tons, suitable for transporting heavy goods such as large machinery and steel.
2.Adapt to various road conditions: The three axle flatbed semi-trailer has a large number of tires, which can disperse the total weight of the vehicle, reduce the contact pressure per unit area, and enable it to perform well on muddy or uneven roads.
3.Convenient loading and unloading, the flat design makes the loading and unloading of goods more convenient and efficient, especially for heavy or large goods such as construction machinery, which can significantly improve logistics transportation efficiency.
Three Axle Flatbed Semi-Trailer
Applicable in many fields, three-axle flatbed semi-trailers are widely used in engineering construction, logistics transportation, agriculture and other fields. They can be used to transport a variety of goods such as large equipment, steel, agricultural machinery, etc. With the development of the logistics industry, the design and manufacturing technology of three-axle flatbed semi-trailers will continue to improve, and more lightweight, environmentally friendly and intelligent models may appear in the future, further improving transportation efficiency and safety.
The three-axle flatbed semi-trailer has a large number of tires, which can disperse the total weight of the vehicle body and reduce the contact pressure per unit area, allowing it to perform well on muddy or uneven roads.
The body is flat and the chassis is low, which is convenient for loading and unloading heavy or large goods, such as construction machinery, transport vehicles, etc. It is equipped with three axles to improve the carrying capacity and stability. The common length is 13.75 meters or 13.8 meters, the width is generally 3 meters, and some models can be 2.8 meters. The body height is low, usually around 1.6 meters, and the cargo platform height can be selected according to needs.
Product Paramenters
一、半挂车型号和主要配置： | |||
外形尺寸（长度和宽度：最外端不可拆解的金属物之间；栏板车高度为厢板高度，仓栅车高度为底板至仓栅顶部高度，厢车为厢高高度）长： 13.6米； 宽： 2.5 米； 高： | |||
产品名称： 三轴平板半挂车 产品型号：出口型 上牌吨位： 数量：台 | |||
纵梁高度（mm) | 锰钢 400 mm | 轴距 | 按设计 |
纵梁上下翼板厚度（mm) | 14mm/ 14mm T700 | 是否带篷布杆 | / |
纵梁腹板厚度（mm) | 8/6 mm T700 | 是否带篷布架（爬梯） | / |
边梁规格 | 160折弯件 4mm/T700 | 箱内横拉、斜拉样式 | / |
贯穿梁规格 | 80*50*3型材 | 支腿形式 | 28吨 单动 外置 |
牵引销规格 | 50#装配 JOST | 工具箱尺寸/数量 | 标准 一个 长度按照设计 |
悬挂系统 | 国产空气悬架 前桥提升 | 后防护网形式 | 按设计 |
立板加固 | 内加固 | 备胎架规格/数量 | 2个 |
低平板前脖 | 颜色（与主机颜色可能有色差） | 车架：5005 烤漆/聚氨酯 | |
车厢：5005 烤漆/聚氨酯 | |||
防水槽 | 无 | 轮胎规格/数量 | 名称：玲珑轮胎 |
底板形式/厚度（mm） | 28mm 2.5厚高强 | 445/45R19.5 | |
厢板形式/扇数 | / | 7条 | |
合页形式 | / | 钢圈规格/数量 | 7只 |
仓栅开启方式 | / | 车轴数及型号 | 型号：德式桥 |
立柱样式/节数/高度 | / | 板簧片数/规格 | 空气悬架 |
/ | 前桥提升 手控阀操作 | ||
仓栅高度/间距/层数 | / | 分泵规格/数量 | 6双 /2单 |
仓栅后门样式 | / | 制动阀规格 | 三桥同步阀 |
厢式门是否带密封条 | / | “ABS”规格 | 有 |
l 所运输货物及工况的特殊要求描写（货物名称，形状特征，运输路况，作业环境及其他）： | |||
