HOWO 6 × 4 White Dump Truck
1.Howo dump trucks have different horsepower levels, including 336 horsepower, 371 horsepower, 380 horsepower, and 420 horsepower. You can select the truck that meets your requirements according to your needs. There are two types, namely front - lift and middle - lift. The front - lift type has a stronger lifting force, while the middle - lift type is relatively less expensive and easier to maintain. You can choose the one that is more suitable for you according to your usage.
2.The dumper truck adopts the internationally popular design concept and MAN vehicle technology, and integrates leading technology assemblies both at home and abroad. The improved adaptive technology endows the vehicle with the characteristics of high load - bearing, high speed, high reliability, high comfort and high efficiency.
3.Howo 6x4 dump truck overall dimension is 8650mm*2500mm*3300mm. It can transport sand,stone,gravel and other goods. loading capacity is 25-40tons. Chengda also provides different color and painting your logo for free.
HOWO 6 × 4 White Dump Truck
Howo Dump Truck is left hand driving system with 371HP, WD615.47 engine. HW76 cabin with one sleeper bed. Dump truck can load about 20-30ton cargos, with strong and durable usage, it geared up with ABS braking system, widening brakes and engine in-cylinder brakes, ABS maintains the directionality and operability at some factor of braking, and the provider braking makes the vehicle continuously defend the exceptional braking state, and the auto brakes stably The typical overall performance and braking effectivity are drastically enhanced.
Howo 6x4 371hp tipper dump vans upkeep performs a giant position in stopping any accidents. Our Howo 6x4 371hp tipper new dump truck can use lengthy time solely you make ordinary maintenance. Check suspension structures whilst the dump truck is loaded to make positive they work desirable and have steady suspension. Don't forget about to exchange susceptible suspension systems. Check tires pressures each day. Tires stress ought to be the equal on each aspects of the truck. Check hoist cylinders frequently. Don't forget about to trade worn cylinders.
Product Paramenters
MODEL/车型 | ZZ3257M3866C | ||
Driver position/驾驶员位置 | Left Hand | ||
Driving type/驱动形式 | 6*4 | ||
Wheelbase/轴距(mm) | 3775+1400 | ||
Max. Speed/最高车速(km/h) | 100 km/h | ||
Engine/发动机 | Brand/品牌 | 重汽 | |
Model/型号 | WD615.47 | ||
Emission Standard/排放 | EURO II | ||
Rated output power/功率（PS） | 371HP/273KW | ||
Cylinder in line 直列缸数 | 6 | ||
Air filter element/空滤器 | Oil bath air filter 油浴式空滤器 | ||
Displacement (L)/排量 | 10L | ||
Transmission/变速箱 | Type 类型 | Manual 手动 | |
Model/型号 | SINOTRUK HW19710 10-speed manual transmission 中国重汽HW19710 10挡 手动变速箱 | ||
Front axle/前轴 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | HF9 | ||
Rear axle/后桥 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | 16T AC16双级减速桥 double reduction driving axle Speed ratio 速比：5.262 | ||
Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | ||
Steering/转向机 | ZF technology/ ZF技术 | ||
Frame/车架 | Type 类型 | Bottle neck, double frame前宽后窄，双层车架 | |
Dimension (mm) 车架尺寸 | 940-850 (W) 300 (H) | ||
Section thickness (mm) 厚度 | 8+8 | ||
Suspension/悬架 | Front 前悬架 | Semi-elliptic 多片簧 12pcs | |
Rear 后悬架 | Semi-elliptic 多片簧 14pcs | ||
Fuel tank/燃油箱 | 300L铝合金 Aluminum alloy | ||
Wheels and tires/轮胎 | 295/80 R22.5 | ||
Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | ||
Parking brake:Air discharging with spring control/停车制动 | |||
Auxiliary brake:Engine exhaust brake/发动机排气辅助制动 | |||
CAB INTERIOR 驾驶室内部配置 | Driver seat 驾驶室座椅 | mechanical 机械式 | |
Lighter 点烟器 | Yes | ||
Entertainment 娱乐设置 | mp3+radio | ||
Cab maintanence titled 驾驶室翻转 | manual 手动翻转 | ||
Air conditioner 空调 | manual手动空调 | ||
Rear view mirror 后视镜 | manual手动 | ||
Sleeping bed 卧铺 | single bed 单卧铺 | ||
CARGO BOX SPECS/自卸车大箱参数 | DIMENSIONS (mm) 尺寸 | 5800x2300x1500(LxWxH) | |
Material 材质 | 高强钢 T700 | ||
Lifting system 举升缸 | JIAHENG 179 | ||
Thickness(mm) 板材厚度 | Bottom 10mm, sides 8mm 底板10mm，边板8mm | ||
OVERALL DIMENSIONS/全车尺寸 | 8650×2550×3300 mm | ||
