HOWO 8 × 4 Red Square Box Self Dumping
1.Good comfort. The cab adopts four-point suspension, mechanical seat, flexible suspension and other designs to effectively reduce vehicle bumps and improve riding comfort. The cab is highly sealed and has dustproof, heat-insulating, noise-reducing and other functions, providing the driver with a quiet and comfortable driving environment. Some models are equipped with airbag shock-absorbing seats, multi-function steering wheels, manual air conditioners, etc., which improve the convenience and comfort of driving.
2.The chassis is high, and the approach and departure angles of the vehicle are reasonably designed, which can adapt to various complex road conditions, such as construction sites, mines and other environments with poor road conditions. The tire specifications are large, equipped with large-size radial steel tires, such as 12.00R20 tires, and the pattern adopts a mahjong block design with stronger grip, which is conducive to improving the ability to escape from difficult environments.
HOWO 8 × 4 Red Square Box Self Dumping
The engine is WD615.47, with a pressure shape of 8X4 and a maximum horsepower of 371. The transmission adopts AMT elite transmission, with up to 10 gears, and the continuity of power, transmission capacity, and burst pressure are all outstanding. HOWO trains its dump truck by using a tuning strategy during the transition phase, allowing the engine and transmission to operate at their optimal state. When you step on the accelerator, it generates a constant response pressure, allowing the driver to feel the true joy of control. Overall, HOWO dump trucks have significant advantages in terms of power and response capabilities compared to similar models.
HOWO dump trucks are mainly used for some medium and short-distance transportation, some heavy goods such as sand and gravel, and can also be used for other goods. We have dump trucks HOWO of different tonnages, including 4x2 about 15 tons, 6x4 about 25 tons, 8x4 about 40 tons, etc., which can meet your different truck needs. Contact now.
Product Paramenters
MODEL/车型 | ZZ3257M3866C | ||
Driver position/驾驶员位置 | 左舵 Left Hand | ||
Driving type/驱动形式 | 8*4 | ||
Wheelbase/轴距(mm) | 1950+3225+1350 | ||
Max. Speed/最高车速(km/h) | 100 km/h | ||
Engine/发动机 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | WD615.47 | ||
Emission Standard/排放 | EURO Ⅱ | ||
Rated output power/功率（PS） | 371HP/276KW | ||
Cylinder in line 直列缸数 | 6 | ||
Displacement (L)/排量 | 9.97L | ||
Transmission/变速箱 | Type 类型 | Manual 手动 | |
Model/型号 | SINOTRUK HW19710 10-speed manual transmission 中国重汽HW19710 10挡 手动变速箱 | ||
Front axle/前轴 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | HF9 | ||
Rear axle/后桥 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | 16T AC16双级减速桥 double reduction driving axle Speed ratio 速比：5.262 | ||
Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | ||
Steering/转向机 | ZF technology/ ZF技术 | ||
Frame/车架 | Type 类型 | Bottle neck, double frame前宽后窄，双层车架 | |
Dimension (mm) 车架尺寸 | 940-850 (W) 300 (H) | ||
Section thickness (mm) 厚度 | 8+8+8 | ||
Suspension/悬架 | Front 前悬架 | Semi-elliptic 多片簧 12pcs | |
Rear 后悬架 | Semi-elliptic 多片簧 14pcs | ||
Fuel tank/燃油箱 | 300L铝合金 Aluminum alloy | ||
Wheels and tires/轮胎 | 12.00R20 | ||
Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | ||
Parking brake:Air discharging with spring control/停车制动 | |||
Auxiliary brake:Engine exhaust brake/发动机排气辅助制动 | |||
CAB INTERIOR 驾驶室内部配置 | Driver seat 驾驶室座椅 | mechanical 机械式 | |
Lighter 点烟器 | Yes | ||
Entertainment 娱乐设置 | mp3+radio | ||
Cab maintanence titled 驾驶室翻转 | manual 手动翻转 | ||
Air conditioner 空调 | manual手动空调 | ||
Rear view mirror 后视镜 | manual手动 | ||
Sleeping bed 卧铺 | single bed 单卧铺 | ||
CARGO BOX SPECS/自卸车大箱参数 | DIMENSIONS (mm) 尺寸 | 7800x2300x1500+250mm (LxWxH) | |
Material 材质 | 高强钢 T700 | ||
Lifting system 举升缸 | JIAHENG 191 | ||
Thickness(mm) 板材厚度 | Bottom 10mm, sides 8mm 底板10mm，边板8mm | ||
OVERALL DIMENSIONS/全车尺寸 | 10080×2550×3300 mm | ||
