White Shaanqi H3000 Tractor Truck
1.A variety of engine options, equipped with WP10 and WP12 series engines, with horsepower ranging from 336-430hp, to meet different transportation needs.The efficient transmission system is matched with the 12JSD180 gearbox, which has high transmission efficiency, smooth gear shifting and improved fuel economy.
2.The reinforced axle adopts MAN 7.5T technology for the front axle and 13T series for the rear axle, which has strong load-bearing capacity and can adapt to complex road conditions. The large-capacity saddle is equipped with a 90# saddle, which can match a variety of trailers to improve transportation efficiency.
White Shaanqi H3000 Tractor Truck
Equipped with Weichai series engines, the WP10 engine has a displacement of 9.726 liters and a maximum horsepower of 380. It has a higher horsepower output and stronger power, making it suitable for transportation scenarios with higher power requirements, such as mountain roads or heavy-load transportation, while maintaining good fuel efficiency. During the design and manufacturing process of the engine, attention was paid to reliability, fuel economy and environmental protection performance, which can meet the transportation needs of different users.
The humanized cab has an extended flat roof design, spacious space, luxurious interior, and optional air suspension seats, electric sunroof, etc. to reduce driving fatigue. High-quality sound insulation effect, good sealing of the cab, effectively isolates noise and provides a quiet driving environment.
Product Paramenters
MODEL/车型 | ZZ3257M3866C | |
Driver position/驾驶员位置 | 左舵 Left Hand | |
Driving type/驱动形式 | 6*4 | |
Wheelbase/轴距(mm) | 3175+1400mm | |
Max. Speed/最高车速(km/h) | 100 km/h | |
Engine/发动机 | Brand/品牌 | WEICHAI/潍柴 |
Model/型号 | WP10 | |
Emission Standard/排放 | EURO II | |
Rated output power/功率（PS） | 380HP/283KW | |
Displacement (L)/排量 | 10L | |
Transmission/变速箱 | Brand/品牌 | FAST/法士特 |
Model/型号 | 12JSD180 | |
Front axle/前轴 | Model/型号 | MAN 9T |
Rear axle/后桥 | Model/型号 | HANDE 汉德 16T |
Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | |
Steering/转向机 | ZF technology/ ZF技术 | |
Fuel tank/燃油箱 | 400L铝合金 Aluminum alloy | |
Frame/车架 | 850x300(8+8) | |
Wheels and tires/轮胎 | 12R22.5 | |
Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | |
Parking brake:Air discharging with spring control/停车制动 | ||
Auxiliary brake:Engine exhaust brake/发动机排气辅助制动 | ||
驾驶室 | 液压主座椅、四点机械悬浮驾驶室、电控自动恒温空调、手动摇窗机、手动翻转、油浴式空滤器、金属保险杠 二级上车踏板，165Ah 维护蓄电池 Hydraulic main seat, four-point mechanical suspension cab, electronically controlled temperature air conditioner, manual operation window shaker, manual flip, oil bath air filter, metal bumper Two-stage car pedal, 165Ah maintenance battery, SHACMAN identification | |
