HOWO 8 × 4 Box Type Truck
1.The cargo box has a size of 10200x2700x2700, and the cargo compartment is spacious, which can provide a large cargo space and load more cargo, fully meeting the needs of logistics and transportation. Comfort configuration, optional airbag shock-absorbing seats, four-point airbag suspension, etc., provide a comfortable driving experience, create a quiet and comfortable driving environment for the driver, and effectively reduce long-distance driving fatigue.
2.The chassis adopts a high-strength double-layer frame, equipped with Sinotruk HC13 rear axle and HF9 front axle to ensure the vehicle's carrying capacity and stability. It is matched with Sinotruk HW19710 10-speed manual transmission, which is easy to operate and has high transmission efficiency.
HOWO 8 × 4 Box Type Truck
The Sinotruk gearbox/axle is used, which has been verified for a million kilometers, adapts to harsh working conditions, and extends the maintenance cycle. The frame and cargo box are optimized, the 8+8 frame layout has strong tensile resistance, and the cargo box is made of high-strength steel + reinforced pressure point design, which is wear-resistant and deformation-resistant.
In terms of fuel efficiency, the HOWO 8×4 box truck has a dedicated power train calibration to ensure strong power while achieving lower fuel consumption. In addition, the vehicle is also equipped with a two-stage air filter system to effectively protect the engine, extend its service life, further reduce maintenance costs, and improve overall operating economy.
Product Paramenters
MODEL/车型 | ZZ3257M3866C | ||
Driver position/驾驶员位置 | 左舵 Left Hand | ||
Driving type/驱动形式 | 8*4 | ||
Wheelbase/轴距(mm) | 1950+4225+1350 | ||
Max. Speed/最高车速(km/h) | 100 km/h | ||
Engine/发动机 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | WD615.47 | ||
Emission Standard/排放 | EURO Ⅱ | ||
Rated output power/功率（PS） | 371HP/276KW | ||
Cylinder in line 直列缸数 | 6 | ||
Displacement (L)/排量 | 9.97L | ||
Transmission/变速箱 | Type 类型 | Manual 手动 | |
Model/型号 | SINOTRUK HW19710 10-speed manual transmission 中国重汽HW19710 10挡 手动变速箱 | ||
Front axle/前轴 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | HF9 | ||
Rear axle/后桥 | Brand/品牌 | SINOTRUK /重汽 | |
Model/型号 | HC13 速比：4.7 | ||
Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | ||
Steering/转向机 | ZF technology/ ZF技术 | ||
Frame/车架 | Type 类型 | Bottle neck, double frame前宽后窄，双层车架 | |
Dimension (mm) 车架尺寸 | 940-850 (W) 300 (H) | ||
Section thickness (mm) 厚度 | 8+8 | ||
Suspension/悬架 | Front 前悬架 | Semi-elliptic 多片簧 12pcs | |
Rear 后悬架 | Semi-elliptic 多片簧 14pcs | ||
Fuel tank/燃油箱 | 300L铝合金 Aluminum alloy | ||
Wheels and tires/轮胎 | 12.00R20 | ||
Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | ||
Parking brake:Air discharging with spring control/停车制动 | |||
Auxiliary brake:Engine exhaust brake/发动机排气辅助制动 | |||
驾驶室配置 （高顶） | Driver seat 驾驶室座椅 | mechanical 机械式 | |
Lighter 点烟器 | Yes | ||
Entertainment 娱乐设置 | mp3+radio | ||
Cab maintanence titled 驾驶室翻转 | manual 手动翻转 | ||
Air conditioner 空调 | manual手动空调 | ||
Rear view mirror 后视镜 | manual手动 | ||
Sleeping bed 卧铺 | single bed 单卧铺 | ||
货箱参数 | Material 材质 | 高强钢 Q355 | |
Lifting system 举升缸 | JIAHENG 191 | ||
Thickness(mm) 板材厚度 | Bottom 5mm, sides 3mm 底板5mm，边板3mm | ||
DIMENSIONS (mm) 尺寸 | 10200x2700x2700(LxWxH) | ||
Other 其他 | 工具箱（两个）Toolbox (two) | ||
