Shaanxi Automobile H3000 6×4 Green Tractor Truck
1.The Shaanxi Automobile Delong H3000 6 × 4 tractor is a high-end heavy-duty truck designed specifically for efficient long-distance transportation. It integrates advanced technology and reliable performance, leading the industry benchmark with excellent power, fuel efficiency, and driving comfort.
2.Equipped with Weichai WP10 series engine (optional 380 horsepower version), matched with a Fast 12 speed gearbox, the power output is stable and strong, and the acceleration on hills is easy to handle. National II emissions, balancing environmental protection and performance, adaptable to various road conditions
Shaanxi Automobile H3000 6×4 Green Tractor Truck
The driving form is a classic layout of 6 × 4, equipped with MAN technology front axle and Hande rear axle (front axle 9T, rear axle 16T), with a load-bearing capacity of up to 50 tons. The suspension system is designed with fewer leaf springs and steel plate springs, balancing comfort, stability, and durability to reduce maintenance costs.
The engine and gearbox are precisely matched, and the comprehensive fuel consumption per 100 kilometers is 3-5% lower than similar models, saving over 20000 yuan in fuel costs annually. Lightweight design, application of aluminum alloy components, vehicle weight ≤ 8.8 tons, compliant with multiple loads, improving operational efficiency.
The cab is equipped with a hydraulic main seat, a four point mechanical suspension cab, an electrically controlled automatic constant temperature air conditioner, a manual window shaking machine, a manual flip, an oil bath air filter, a metal bumper, a secondary boarding pedal, and a 165Ah maintenance battery. The cab has strong sealing, dust prevention, heat insulation, and noise reduction functions, providing a quiet and comfortable driving environment for the driver.
Product Paramenters
MODEL/车型 | ZZ3257M3866C | |
Driver position/驾驶员位置 | 左舵 Left Hand | |
Driving type/驱动形式 | 6*4 | |
Wheelbase/轴距(mm) | 3175+1400mm | |
Max. Speed/最高车速(km/h) | 100 km/h | |
Engine/发动机 | Brand/品牌 | WEICHAI/潍柴 |
Model/型号 | WP10 | |
Emission Standard/排放 | EURO II | |
Rated output power/功率（PS） | 380HP/283KW | |
Displacement (L)/排量 | 10L | |
Transmission/变速箱 | Brand/品牌 | FAST/法士特 |
Model/型号 | 12JSD180 | |
Front axle/前轴 | Model/型号 | MAN 9T |
Rear axle/后桥 | Model/型号 | HANDE 汉德 16T |
Clutch/离合器 | ￠430 diaphragm clutch￠430离合器 | |
Steering/转向机 | ZF technology/ ZF技术 | |
Fuel tank/燃油箱 | 400L铝合金 Aluminum alloy | |
Frame/车架 | 850x300(8+8) | |
Wheels and tires/轮胎 | 12R22.5 | |
Brakes/制动 | Running brake:Dual circuit compressed air brake/行车制动 | |
Parking brake:Air discharging with spring control/停车制动 | ||
Auxiliary brake:Engine exhaust brake/发动机排气辅助制动 | ||
驾驶室 | 液压主座椅、四点机械悬浮驾驶室、电控自动恒温空调、手动摇窗机、手动翻转、油浴式空滤器、金属保险杠 二级上车踏板，165Ah 维护蓄电池 Hydraulic main seat, four-point mechanical suspension cab, electronically controlled temperature air conditioner, manual operation window shaker, manual flip, oil bath air filter, metal bumper Two-stage car pedal, 165Ah maintenance battery, SHACMAN identification | |
